18/14 SOOW Portable Cord Applications:
SOOW Flexible Cord applications include portable tools and equipment, portable appliances, small motors and associated machinery
Features:
Excellent resistance to oil and moisture. Good tensile strength, elongation and aging characteristics. High flexibility. Excellent abrasion resistance. Sunlight-resistant. UL Listed and CSA Certified for indoor and outdoor use. Temperature range: -40ºC to +90ºC
Standards:
UL Flexible Cord – UL Subject 62
CSA Flexible Cord – C22.2-49
MSHA Approved
RoHS Compliant
Construction:
Conductors:
18 through 2 AWG fully annealed stranded bare copper per ASTM B-174
Insulation:
Premium-grade, color-coded 90ºC EPDM.
18/14 SOOW Portable Cord Specifications:
Size: 18 AWG
Number of Conductors: 14
Conductor Strand: 16/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.630 inches
Weight: 0.265 lbs per ft
Current Amps: 3.5
18/14 SOOW Portable Cord More Information
| Cable Type | SOOW – 600V |
| Wire Size | 18 AWG |
| # of Conductors | 14 Conductors |
| Conductor Material | Bare Copper |
| Stranded or Solid | Stranded |
| O.D. (Inches) | 0.63 |
| Ampacity | 3.5 |
| Voltage | 600V |
| Temp. Rating | -40°C ~ 90°C |
| Insulation Material | EPDM Rubber |
| Jacket Material | CPE – Chlorinated Polyethylene |
| Flexibility | High Flexibility |
| Indoor/Outdoor Use | Indoor, Outdoor |
| Shielded | No |
| Standards | UL Listed, CSA Certified, RoHS Compliant, MSHA Approved |
| Features | Weather Resistant, Water Resistant, Oil Resistant |
