18/5 SJTO Portable Cord Applications:
SJTO Flexible Cord applications include portable tools, motors, floor maintenance equipment, hospital equipment, sound equipment, washing machines, portable lights, lamps and similar equipment.
Jacket:
Polyvinylchloride (PVC), Black. Temperature range: -20ºC to +60ºC. Voltage rating: 300 Volts.
Features:
Oil resistant jacket. Resists: Oils, Acids, Alkalies, Ozone
Standards:
UL Flexible Cord – UL Subject 62
MSHA Approved (where applicable)
Construction:
Conductors:
18 through 6 AWG fully annealed stranded bare copper per ASTM B-174
Insulation:
Premium-grade, color-coded PVC.
18/5 SJTO Portable Cord Specifications:
Size: 18 AWG
Number of Conductors: 5
Conductor Strand: 16/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 10.06 mm / 0.396 inches
Weight: 0.088 lbs per ft
Current Amps: 7(Green conductor for grounding only)
Color Code:
5 Conductors: Black, White, Red, Green, Orange
18/5 SJTO Portable Cord More Information
| Wire Size | 18 AWG |
| # of Conductors | 5 Conductors |
| O.D. (Inches) | 0.396 |
| Ampacity | 5.6 |
