18/6 SJTOW Portable Cord Applications:
18/6 SJTOW Flexible Cord applications include portable tools, motors, floor maintenance equipment, hospital equipment, sound equipment, washing machines, portable lights, lamps and similar equipment.
Jacket:
Polyvinylchloride (PVC), White jacket . Temperature range: -40ºC to +105ºC. Voltage rating: 300 Volts.
Features:
Oil resistant jacket. Resists: Oils, Acids, Alkalies, Ozone
Standards:
UL Flexible Cord – UL Subject 62
MSHA Approved (where applicable)
Construction:
Conductors:
18 through 10 AWG fully annealed stranded bare copper per ASTM B-174
Insulation:
Premium-grade, color-coded PVC.
18/6 SJTOW Portable Cord Specifications:
Size: 18 AWG
Number of Conductors:6
Conductor Strand: 16/30
Insulation Thickness: 0.762 mm / 0.030 inches
Outside Diameter: 10.16 mm / 0.400 inches
Weight: 0.110lbs per ft
Current Amps:5.6 (Green conductor for grounding only)
Color Code:
6 Conductors: Black, White, Green, Red, Brown, Purple
18/6 SJTOW Portable Cord More Information
| Wire Size | 18 AWG |
| # of Conductors | 6 Conductors |
| O.D. (Inches) | 0.4 |
| Ampacity | 5.6 |
